The small gas boiler THERM PRO 14 XZ.A can heat water in an external reservoir and in water-heat systems it works in the same way as heating only boilers. The external reservoir is heated by an integrated three-way valve that is part of the wall boiler. Two types of the boiler are available according to the type of fuel, i.e. boiler combustion natural gas or propane.

The boiler is for heating of buildings with a heat loss up to 14.0 kW. When developing and manufacturing the emphasis was on maximum efficiency and minimum emissions into the air. With its wide range of types and reservoir volumes this boiler can produce relatively high amounts of hot water to satisfy both usual households as well as demanding clients requiring high comfort.



Recommended retail price: on request

eu_flagThe product THERM PRO 14 XZ.A complies all legislative, safety, healthy and environmental requirements of the European Union and CE mark enables the free movement of products within the market of the European Economic Area.

Information Sheet

Do you have a question?
Do you need installation?
Emission category NOx 6View the ErP labelView the ErP label
  • The boiler contains a three-way valve for alternatively heating the heating system and the hot water storage tank
  • Water cooled low-emission burner
  • Simple and intuitive control
  • Fluent boiler output regulation
  • Can be regulated according to the spatial or outdoor temperature (equitherm regulation)
  • Can be controlled by a room thermostat or intelligent room regulator through OpenTherm+
  • The boilers have a ‘low-emission burner’ with very low CO and NOx emissions
  • As standard the boilers have a white cladding
Energy efficiency class of water heating

B

Declared loading profile

L

Nominal thermal input power

15.25

Min. – max. thermal output for heating

5.0 – 14.0

Fuel

natural gas / propane

Gas consumption - natural gas

0.58 – 1.62

Gas consumption - propane

0.21 – 0.59

Min. – max. overpressure of heating system

0.8 – 3.0

Maximum input pressure of heating water

80

Boiler efficiency

92

Volume of expansion unit

7

Nominal supply voltage / frequency

230/50~

Level of coverage of electrical part

IP 44 (D)

Diameter of smoke flue

110

Dimensions: height / width / depth

800 / 430 / 275

Weight of boiler

30

Order number

1001.7
